HOWO Mining King
| Product Description: | ZZ5707S3840A |
| Brand: | China National Heavy Duty Truck HOWO Mining King |
| Model: | ZZ5707S3840A |
| Type: | Van |
| Fuel type: | diesel |
| Door number: | one door |
| Seat row: | single row |
| Emission standard: | national three |
| Processing Customisation: | Yes |
| Engine Model: | ZZ3257N38DA |
| Engine displacement: | mine king L |
| Driving form: | 6×4 |
| Transmission type: | HW21712 |
| Cargo compartment size: | 5800*3100*1800m |
| Maximum speed: | 45km/h |
| Hundred kilometres fuel consumption: | 38L |
| Occupants/seats: | 2 |
| Number of steel plate spring: | 2 |
| Chassis Model: | ZZ5707S3840A |
| HOWO Mining Warrior Configuration: | HOWO Mining King |
China National Heavy Duty Truck 371 horsepower Europe II emissions, HW19710 transmission, AC26 drive axle 10.47 speed ratio, HF12 front axle, ZF8098 steering wheel, suspension system reinforced, 14.00-25 mining tyres (36-ply), cab HW7D.
Compartment: (5600, 5800, 5900)*3100*(1500, 1800, 2000,2200) bottom 14, 16, 18 side 14, 12, 10 (steel plate thickness can be done according to user requirements), manganese plate reinforced material for the whole vehicle, imported Haiwu 169 or 191 lifting cylinders, five longitudinal beams at the bottom of the box with reinforced design, and other according to the Heavy Duty Trucks with reinforced type. Other configurations are according to Heavy Duty Truck.
HOWO 50 (HOWO) Mining Warrior and HOWO 70 (HOWO) Mining King
In 2011, China National Heavy Duty Truck (CNHTC) launched a series of mining brothers---HOWO Mining Warrior and HOWO Mining King. Since the launch of 50-type mining dump truck in 2007, China National Heavy Duty Truck (CNHTC) has accumulated a large amount of practical data and user experience, and has fully mastered the application characteristics and special technology of mining dump trucks.
Common features of mine brothers:
The engine is equipped with electric heating device for air intake system, which makes it not difficult to start the vehicle in cold weather. The pre-filter + oil bath + air filter three-level air filter of the air intake system can effectively filter out the dust, which effectively prevents the engine from early wear and prolongs the service life.
For the convenience of top-loading modification, the exhaust pipe is reserved for the position of heated air extraction on the top-loading base plate of the dump truck.
The strengthened front and rear leaf springs make the chassis able to cope with all kinds of harsh operating environments.
200L cooling water tank and water spraying device are equipped as standard, which can cool down the braking system more conveniently and quickly and improve the braking safety.
High section, high strength vehicle price provides a solid skeleton for your vehicle.
Howo 50 (HOWO) Mining Warrior Features:
Performance tough: Adhering to the design advantages of 70 mine bully, synchronous technology to improve, strong performance.
Excellent price: Large-scale production, the price is better than other manufacturers of similar products, easier for users to buy.
Strong competition: With the 70 Mining Warrior, it forms a complete mining truck platform of China National Heavy Duty Truck (CNHTC), which demonstrates the strong competitiveness of CNHTC's mining trucks.
Wide application: 50 Mining Warrior is more suitable for narrow and harsh working conditions than 70 Mining King.
High efficiency: Equipped with China National Heavy Duty Truck's self-developed AC16 axle (speed ratio 6.5), the high speed can reach 75KM/h, which greatly improves the transport efficiency.
Fast money-making: The carrying capacity of 50 Mining Warrior is 1.5 times of that of ordinary dump trucks, making money fast and with high return rate.
Equipped with HW19710 gearbox with HW50 extractor, HW70 extractor is also optional.
500 litre D-type fuel tank is adopted to meet the requirement of large workload for the vehicle.
The new front axle adopts reinforced wide-body welded box-type steel front axle, which is more suitable for the bad working conditions in the mining area.
The rear axle adopts AC16 reinforced wide-body cast steel two-stage deceleration drive axle with 6.5 speed ratio.
Wheels and tyres: 10.0/2-20 wheel assembly, standard 14.00-20-28PR tyres, optional 14.00R20-28PR tyres, which is more suitable for bad working conditions in mines.
Mining Warrior special reinforced wide-body frame.
German ZF9098 steering wheel.
Air conditioner
HF10 front axle.
HOWO 70 (HOWO) mine bully features
Single-side high-strength skeleton cab, simple shape, hard, wide field of vision; good sealing to ensure that your vehicle is always in a safe and comfortable driving environment; cab above the front and rear of each of the two illuminated lamps to facilitate night operations.
Equipped with HW19710 gearbox, HW70 power take-off, torque up to 700NM.
500 litre D-type fuel tank (400 litre fuel tank is optional) is adopted to meet your requirement of large workload.
The new front axle assembly independently developed by China National Heavy Duty Truck (CNHTC) applies the technology of integral casting I-beam, 500x210 reinforced brake and other parts assembly suitable for mining trucks.
The rear axle adopts AC26 mining drive axle, the main reduction structure design is more reasonable, and the reinforced casting axle shell and drum brake make the vehicle's carrying capacity and braking capacity at the leading level in China.
Wheels and tyres: 10.0/2-25 wheel assembly, standard 14.00-25-36PR tyres, original 14.00R25-36PR tyres, is specially tailored for the mine king of high load-bearing, high wear-resistant special tyres.
HOWO mine king is heavy truck centralised engineering staff and development, the primary for all kinds of open-pit mines, steel mills, hydropower construction sites, ports and other poor road conditions, the work situation is very bad occasions, engaged in the regional scope of the short-distance transit business the development of this car, for the specially designated user groups, with a high degree of economic efficiency and social benefits!
