HOWO Truck
Basic Information Model: ZZ1317M3867C
Type: Truck
Drive: 8X4
Wheelbase: 1800+3800+1350mm
Engine: CNHTC WD615.92E
Type: Truck
Drive: 8X4
Wheelbase: 1800+3800+1350mm
Engine: CNHTC WD615.92E
Send Inquiry
Product Introduction
HOWO Truck 266hp 8X4 Pallet Truck (ZZ1317M3867C)
Basic Information Model: ZZ1317M3867C
Type: Truck
Drive: 8X4
Wheelbase: 1800+3800+1350mm
Engine: CNHTC WD615.92E
Transmission
| China Heavy Duty Truck: | HW13710 |
| Length: | 11.18 metres |
| Width: | 2.496 metres |
| Height: | 3.115 metres |
| Front wheelbase: | 2022/2022 mm |
| Rear wheelbase: | 1830/1830 mm |
| Overall vehicle weight: | 11.17 tonnes |
| Rated load capacity: | 19.7 tonnes |
| Gross mass: | 31 tonnes |
| Maximum speed: | 102 km/h |
| Origin: | Jinan, Shandong, China Jinan, Shandong, China |
| Tonnage: | Heavy duty truck |
| Market Segment: | Construction material transport, agricultural and sideline product transport |
| Remarks: | When the vehicle is equipped with high roof cab, the height of the whole vehicle is 3700mm, and the number of passengers is the same as the rated mass. The total mass of the trailer is 9900kg, only for WD615.97E and WD615.97C engine chassis. |
| Fuel type: | diesel |
Engine Parameters
| Engine Model: | China National Heavy Duty Truck WD615.92E |
| Engine Brand: | China National Heavy Duty Truck |
| Engine Name: | China National Heavy Duty Truck WD615 |
| Number of cylinders: | 6 cylinders |
| Fuel Type: | Diesel |
| Cylinder Arrangement: | In-Line |
| Displacement: | 9.726L |
| Emission Standard: | National III |
| Maximum output power: | 196kW |
| Maximum Horsepower: | 266 Horsepower |
| Maximum torque: | 1100N-m |
| Maximum torque speed: | 1100-1600RPM |
| Rated speed: | 2200 RPM |
| Engine Type: | In-line six-cylinder, water-cooled, four-stroke, supercharged intercooler, electronically controlled fuel supply rate fuel injection pump |
Cargo box parameters
| Type of cargo box: | Pallet type |
| Length: | 8.6 metres |
| Width: | 2.326 metres |
| Height of cargo box: | 0.8 metres |
Cab parameters
| Cab: | High roof or flat roof can be selected according to demand |
| Number of passengers: | 2 persons |
| Transmission model: | HW13710, China National Heavy Duty Truck (HW13710) |
| Transmission brand: | China National Heavy Duty Truck |
| Shift mode: | manual |
| Forward gear: | 10 gears |
| Number of reverse gears: | 2 |
| Fuel tank material: | aluminium alloy |
| Fuel tank capacity: | 400 litres |
| Allowable front axle load: | 6500/7000kg |
Twin axles
| Permissible load on rear axle: | 17500kg |
| Number of spring plates: | 4/4/-,4/4/12,11/11/12,11/11/- |
| Tyre size: | 11.00-20 12.00-20 11.00r20 12.00r20 |
| Number of tyres: | 12 pcs |
