LNG CNG Tractor Head

Engine: The whole vehicle is equipped with China National Heavy Duty Truck MT13.44-60 engine, 6-cylinder, compressed natural gas (CNG) (LNG) fuel form, in-line cylinder arrangement, displacement 12.419L, National VI emission standard.

Transmission and chassis: matched with China National Heavy Duty Truck (HW19712CL) transmission, manual shift, 12 forward gears, 2 reverse gears. The speed ratio of rear axle is 4.11, the permissible load capacity of front axle is 7000kg, and the permissible load capacity of rear axle is 18000kg (double axle group).

Dimensions and loading capacity: the wheelbase of the vehicle is 3800+1400mm, the length of the body is 7.48m, the width of the body is 2.496m, and the height of the body is 3.455m. The weight of the vehicle is 8.8 tonnes, the total mass is 25 tonnes and the total towing mass is 40 tonnes. Maximum speed is 110 km/h.

Cab configuration: Cab suspension is four-point airbag suspension, with a capacity of 3 persons and one and a half rows of seats.

The vehicle is also equipped with anti-lock braking system, inter-wheel differential lock and independent air-conditioning.

Engine: HOWO LNG and LNG tractors are equipped with Weichai WP13NG480E61 inline six-cylinder gas engine with a displacement of 12.54 litres, a maximum output of 353 kW (480 hp), a peak torque of 2,300 Nm, and a speed of 800-1,300 rpm.

Transmission and Chassis: The vehicle is equipped with a 12-speed manual transmission, model HW25712XSTCL, from China National Heavy Duty Truck (CNHTC), which is designed with overdrive gears. The speed ratio of rear axle is 4.11, the permissible load of front axle is 7000kg, and the permissible load of rear axle is 18000kg (double axle group).

Dimensions and load capacity: The wheelbase of the vehicle is 3800+1400 mm, the length of the body is 7.48 m, the width of the body is 2.496 m, and the height of the body is 3.455 m. The overall weight is 8 tonnes. The weight of the vehicle is 8.8 tonnes, the total mass is 25 tonnes and the total towing mass is 40 tonnes. Maximum speed is 101 kilometres per hour.

The above models are available with a wide range of engine emission standards.

In general, both CNG and LNG HOWO tractor units offer a high level of performance and configuration for a wide range of heavy-duty transport tasks. The decision on which tractor to choose depends on the actual needs and scenarios of use.
